“When using National Weather Service (NWS) data for AERMOD, data representativeness can be thought of in terms of constructing realistic planetary boundary layer (PBL) similarity profiles and adequately characterizing the dispersive capacity of the atmosphere. As such, the determination of representativeness should include a comparison of the surface characteristics (i.e., zo, Bo and r) between the NWS measurement site and the source location, coupled with a determination of the importance of those differences relative to predicted concentrations.” – AERMOD Implementation Guide
Say what? What does this even mean? More importantly, how would anyone put this into action to select a representative weather station for use with AERMET and AERMOD?
A Framework for decisions in dispersion modeling
To put the guidance into action, you should base your representativeness on four criteria:
- Proximity of the NWS measurement site to the source location;
- Land use comparison between the NWS measurement site and the source location;
- Presence of large geographic features between the NWS measurement site and the source location;
- Wind pattern and climate comparison between the NWS measurement site and the source location.
Making a Decision
To help further along your decision-making process, as well as to document your ideas for public record, you need objective data. Listed below is where to find the information (data and tools) you need to make an informed decision on which NWS stations to select.
For proximity comparisons, the location of NWS stations and the application site are needed. The latitude and longitude coordinates of weather stations can be found from three sources:
Once you have the coordinates, you will need an interface to view and compare locations. Here are three potential tools you can use:
- http://mrcc.isws.illinois.edu/CLIMATE/ (you will have to create a user account, for free);
- Google Maps or Google Earth;
- The NaviKnow GeoDataBase (30-day free trial is available at http://www.naviknow.com/geodatabase/)
For land use comparisons, land use map data can be found at https://www.mrlc.gov/viewerjs/.
The land use maps have a few formats for use with GIS software. You can also use the NaviKnow online land use tool available at http://landuse.naviknow.com/. Create a free user account to use the tool. An example of how to use the tool can be seen in the following video https://vimeo.com/288040452 .
To determine if there are any significant geographic features between a NWS station and an application site, using Google Maps (https://www.google.com/maps) should be sufficient. You can view terrain in 3-D.
To compare wind roses of multiple NWS stations, if there is more than one, wind rose data can be found at http://mrcc.isws.illinois.edu/CLIMATE/ . There is a wealth of other meteorological data available at this site.
Climatological data, such as 30-year average monthly rainfall and temperature data (minimum, maximum, and mean) can be found at http://www.prism.oregonstate.edu/recent/. These data are in a variety of formats depending upon how you want to use it.
Now, when having to select NWS weather stations for your AERMOD modeling analysis, you can follow this framework to aid in your decision-making documentation process and use the data in the links provided.
